In the '1.4 Longitudinal Reinforcement' input dialog box, there is no 'Multiple Selection' of surfaces.
I have to edit the concrete cover for many connected surfaces. Is there any help available in this regard?

Answer

Yes, it is.

It is possible to edit the concrete cover in the first row for the direction d1 and d2 and then switch to the cell in the second line and copy the value from the cell above it with the [F8] key.

This allows you to edit the values relatively quickly for all connected surfaces.

You can also use the button to filter the applied areas to reduce the number of lines displayed. See the link below.
