Verification Example 000080 | 1
Used in
3D Model
Specifications
| Number of Nodes | 4 |
| Number of Lines | 3 |
| Number of Members | 3 |
| Number of Load Cases | 1 |
| Total Weight | 0.062 tons |
| Dimensions (Metric) | 10.076 x 0.076 x 2.038 m |
| Dimensions (Imperial) | 33.06 x 0.25 x 6.69 feet |
| Program Version | 5.12.00 |
0001-01-01
007458
Cable with Concentrated Forces
Used in
3D Model
Specifications
| Number of Nodes | 4 |
| Number of Members | 3 |
| Number of Load Cases | 1 |
| Total Weight | 0.062 tons |
| Dimensions (Metric) | 10.500 x 0.500 x 2.250 m |
| Dimensions (Imperial) | 34.45 x 1.64 x 7.38 feet |
| Program Version | 8.12.00 |
