Pedestrian and Cycle Bridge in Neckartenzlingen
Used in
3D Model
Specifications
| Number of Nodes | 235 |
| Number of Lines | 272 |
| Number of Members | 152 |
| Number of Load Cases | 160 |
| Dimensions (Metric) | 95.298 x 11.290 x 2.528 m |
| Dimensions (Imperial) | 312.66 x 37.04 x 8.29 feet |
| Program Version | 5.09.01 |
2024-05-30
011955
RFEM Model of Pedestrian and Cycling Bridge in Neckartenzlingen, Germany (© IB Miebach)
