Steel Bolted L-Section Connection
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 29 |
| Number of Lines | 36 |
| Number of Members | 3 |
| Number of Surfaces | 19 |
| Number of Solids | 1 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.004 tons |
| Dimensions (Metric) | 0.150 x 0.400 x 0.057 m |
| Dimensions (Imperial) | 0.49 x 1.31 x 0.19 feet |
