2024-05-30
025030
Industrial Warehouse with Rail Beam
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 260 |
| Number of Lines | 320 |
| Number of Members | 281 |
| Number of Surfaces | 8 |
| Number of Load Cases | 4 |
| Number of Load Combinations | 11 |
| Number of Result Combinations | 2 |
| Total Weight | 53.225 tons |
| Dimensions (Metric) | 21.750 x 19.750 x 11.850 m |
| Dimensions (Imperial) | 71.36 x 64.8 x 38.88 feet |
| Program Version | 5.25.01 |
2024-03-09
033281
Stability Analysis of Structures
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 260 |
| Number of Lines | 320 |
| Number of Members | 281 |
| Number of Surfaces | 8 |
| Number of Load Cases | 4 |
| Number of Load Combinations | 11 |
| Number of Result Combinations | 2 |
| Total Weight | 53.225 tons |
| Dimensions (Metric) | 21.750 x 19.750 x 11.850 m |
| Dimensions (Imperial) | 71.36 x 64.8 x 38.88 feet |
| Program Version | 5.25.01 |
