2024-05-30
025156
3D Model Type in RFEM 6
Used in
3D Model
Specifications
| Number of Nodes | 258 |
| Number of Lines | 281 |
| Number of Members | 121 |
| Number of Surfaces | 53 |
| Number of Solids | 0 |
| Number of Load Cases | 7 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 2733.234 tons |
| Dimensions (Metric) | 21,000 x 28,000 x 26,000 m |
| Dimensions (Imperial) | 68.9 x 91.86 x 85.3 feet |
2024-05-30
025155
Model Type 2D|XY|Plate in RFEM 6
Used in
3D Model
Specifications
| Number of Nodes | 22 |
| Number of Lines | 29 |
| Number of Members | 2 |
| Number of Surfaces | 7 |
| Number of Solids | 0 |
| Number of Load Cases | 8 |
| Number of Load Combinations | 1 |
| Number of Result Combinations | 6 |
| Total Weight | 288.795 tons |
| Dimensions (Metric) | 22.000 x 0.000 x 21.000 m |
| Dimensions (Imperial) | 72.18 x 0 x 68.9 feet |
2024-05-30
025236
Model Type 2D|XZ|3D in RFEM 6
Used in
3D Model
Specifications
| Number of Nodes | 4 |
| Number of Lines | 5 |
| Number of Members | 5 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.284 tons |
| Dimensions (Metric) | 3.000 x 3.000 x 0.000 m |
| Dimensions (Imperial) | 9.84 x 9.84 x 0 feet |
