Barrel Vault Structure with Height and Radius Geometry
Perspective view of a half-cylindrical barrel vault showcasing its geometric dimensions based on height and radius.
The image depicts a half-cylindrical barrel vault structure, highlighting its geometric design defined by both the height and radius parameters. The structure's curved form is clearly visible, emphasizing the symmetrical nature of barrel vaults commonly used in construction. No additional contextual information is provided with the image.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 4 |
| Number of Lines | 4 |
| Number of Members | 0 |
| Number of Surfaces | 1 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 9.425 tons |
| Dimensions (Metric) | 4.000 x 2.000 x 6.000 m |
| Dimensions (Imperial) | 13.12 x 6.56 x 19.69 feet |
