Barrel Vault Geometry Visualization
View of a semi-cylindrical barrel vault conceptualized through height and radius geometry.
The image depicts a barrel vault with a semi-cylindrical shape, illustrating its geometry based on height and radius. This type of structure is often used for its efficient load distribution and aesthetic appeal in architectural designs.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 8 |
| Number of Lines | 12 |
| Number of Members | 0 |
| Number of Surfaces | 5 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 9.059 tons |
| Dimensions (Metric) | 4.000 x 1.200 x 6.000 m |
| Dimensions (Imperial) | 13.12 x 3.94 x 19.69 feet |
