Anticlastic Shell Structures over Square Plan
Anticlastic shells form a system of defined spaces with twelve hypar surfaces arranged over a square plan.
The image depicts a series of anticlastic shells, illustrating a systematic approach to space definition using hypar surfaces. The arrangement features twelve distinct hypar surfaces configured over a square plan, demonstrating structural and architectural design techniques. Such structures are characterized by their hyperbolic paraboloid shape, offering unique aesthetic and functional benefits in construction.
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 17 |
| Number of Lines | 28 |
| Number of Members | 0 |
| Number of Surfaces | 12 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 175.307 tons |
| Dimensions (Metric) | 20.000 x 10.000 x 20.000 m |
| Dimensions (Imperial) | 65.62 x 32.81 x 65.62 feet |
