Truncated Obround Solid Visualization
Visualization of a truncated obround solid in engineering software application without brand name reference.
The image shows a geometric visualization of a truncated obround solid. This object features rounded edges and a flattened central area, typical for certain engineering applications. The model is likely used to demonstrate solid modeling capabilities and to explore spatial forms in detail.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 8 |
| Number of Lines | 12 |
| Number of Members | 0 |
| Number of Surfaces | 6 |
| Number of Solids | 1 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 403.140 tons |
| Dimensions (Metric) | 11.000 x 4.000 x 6.000 m |
| Dimensions (Imperial) | 36.09 x 13.12 x 19.69 feet |
