STS008 | Stairs | Three-Flight | Half-Turn (U-Shaped, Switchback)
Model ID 3086 | STS008 | Stairs | Three-Flight | Half-Turn (U-Shaped, Switchback)
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 56 |
| Number of Lines | 77 |
| Number of Members | 77 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.907 tons |
| Dimensions (Metric) | 5.000 x 3.200 x 3.600 m |
| Dimensions (Imperial) | 16.4 x 10.5 x 11.81 feet |
