Inflatable Structure | Pneumatic Membrane Structure
Pneumatic Structure
3D Model
Specifications
| Number of Nodes | 70 |
| Number of Lines | 76 |
| Number of Members | 22 |
| Number of Surfaces | 27 |
| Number of Solids | 1 |
| Number of Load Cases | 7 |
| Number of Load Combinations | 7 |
| Total Weight | 2,540 t |
| Dimensions (Metric) | 33.428 x 26.967 x 8.238 m |
| Dimensions (Imperial) | 109.67 x 88.47 x 27.03 feet |
| Program Version | 5.23.02 |
