Model 004339 | Anchor Plate for Circular Column
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 380 |
| Number of Lines | 245 |
| Number of Members | 30 |
| Number of Surfaces | 128 |
| Number of Solids | 8 |
| Total Weight | 79.184 tons |
| Dimensions (Metric) | 5.132 x 5.463 x 13.595 m |
| Dimensions (Imperial) | 16.84 x 17.92 x 44.6 feet |
| Program Version | 5.27.01 |
