Model 005103 | Beam and Diagonal Braces to Column Flange Connection via Extended End Plate and Tongue Plate
Used in
3D Model
More About 3D Model
Specifications
| Number of Nodes | 6 |
| Number of Lines | 5 |
| Number of Members | 5 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 0 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.153 tons |
| Dimensions (Metric) | 0.640 x 1.300 x 0.000 m |
| Dimensions (Imperial) | 2.1 x 4.27 x 0 feet |
