Model 005467 | Pile Foundation for Bridge Bearing in Soil Model
Model 005467 | Pile Foundation in Soil Solid with Construction Stages
The image shows a pile foundation for a bridge bearing, which is anchored in a soil solid with the modified hardening soil model. The representation includes various construction stages that analyze the stability and load-bearing capacity of the structure. A printout report documents the calculation results and enables a detailed tracking of the construction stages. This analysis is crucial for the design and construction of bridge projects.
3D Model
Specifications
| Number of Nodes | 96 |
| Number of Lines | 153 |
| Number of Members | 86 |
| Number of Surfaces | 14 |
| Number of Solids | 2 |
| Number of Load Cases | 4 |
| Number of Load Combinations | 2 |
| Number of Result Combinations | 0 |
| Total Weight | 68830.130 t |
| Dimensions (Metric) | 45.300 x 36.262 x 40.000 m |
| Dimensions (Imperial) | 148.62 x 118.97 x 131.23 feet |
