Model 005529 | Roof Structure with Glued-Laminated Timber Gable Roof Trusses
The image shows a roof structure with gable roof trusses made of glued-laminated timber, known for its high load-bearing capacity and shape stability. This structure can be modeled and analyzed in Dlubal Software using RFEM or RSTAB to design static and dynamic properties. The use of glued-laminated timber allows for efficient load distribution and provides architectural flexibility.
3D Model
Specifications
| Number of Nodes | 30 |
| Number of Lines | 43 |
| Number of Members | 6 |
| Number of Surfaces | 15 |
| Number of Solids | 0 |
| Number of Load Cases | 10 |
| Number of Load Combinations | 79 |
| Number of Result Combinations | 0 |
| Total Weight | 53.916 t |
| Dimensions (Metric) | 47.000 x 5.065 x 30.000 m |
| Dimensions (Imperial) | 154.2 x 16.62 x 98.43 feet |
