3D Soil Model with FE Analysis
3D soil model, Finite element method, Generated support, Geotechnical analysis
The image shows a three-dimensional display of a soil model that was analyzed using the finite element method. The graphical display visualizes a soil massif with generated support in the form of surface supports, which reflects typical geotechnical engineering conditions.
