Steel Column with Reinforced Concrete Footing
Steel column anchored by a reinforced concrete footing in a construction detail.
A steel column is shown mounted on a reinforced concrete footing. The footing secures the column as part of a typical foundation system. The depicted assembly reflects standard engineering principles for transferring loads to the ground.
3D Model
Specifications
| Number of Nodes | 2 |
| Number of Lines | 1 |
| Number of Members | 1 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 3 |
| Number of Load Combinations | 5 |
| Number of Result Combinations | 2 |
| Total Weight | 0.076 tons |
| Dimensions (Metric) | 0.000 x 2.500 x 0.000 m |
| Dimensions (Imperial) | 0 x 8.2 x 0 feet |
