Plate Girder with Ribs
Steel beam with cross reinforcements and solid wall structure in a detailed view.
The steel beam has a solid wall structure with transverse ribs for reinforcement. Such structures are often used in civil engineering to stabilize the structure and increase load-bearing capacity. The transverse ribs provide additional stiffness under load.
Used in
3D Model
Specifications
| Number of Nodes | 42 |
| Number of Lines | 85 |
| Number of Members | 0 |
| Number of Surfaces | 44 |
| Number of Solids | 0 |
| Number of Load Cases | 3 |
| Number of Load Combinations | 2 |
| Number of Result Combinations | 0 |
| Total Weight | 3.082 t |
| Dimensions (Metric) | 18.675 x 1.007 x 0.390 m |
| Dimensions (Imperial) | 61.27 x 3.3 x 1.28 feet |
