Slope Stabilization with 2 Anchor Rows
Slope stabilization system with two rows of anchor rods for stabilizing a slope.
The photo shows a slope stabilization system using two rows of anchor rods to stabilize a slope. This method provides protection against erosion and collapse by creating an additional layer of stability in the soil. The technique displayed uses special materials and calculation methods to maximize efficiency and ensure safety.
3D Model
Specifications
| Number of Nodes | 26 |
| Number of Lines | 34 |
| Number of Members | 6 |
| Number of Surfaces | 11 |
| Number of Solids | 1 |
| Number of Load Cases | 4 |
| Number of Load Combinations | 6 |
| Number of Result Combinations | 1 |
| Total Weight | 370.282 tons |
| Dimensions (Metric) | 20.000 x 12.000 x 1.000 m |
| Dimensions (Imperial) | 65.62 x 39.37 x 3.28 feet |
