Steel Structure as Facade Support in RFEM 6
Detailed view of a steel structure for facade support in a construction application.
View of a steel facade support that is an integral part of the building facade. The structure shows precisely manufactured fasteners and metal surfaces that provide structural integrity. This solution allows for the attachment of facade panels to supporting frame elements. Such brackets are critical for the safety and aesthetics of modern buildings. This type of structure is usually made of corrosion-resistant steel.
3D Model
No Download Possible
Customer Project / View Only
More About 3D Model
Specifications
| Number of Nodes | 47 |
| Number of Lines | 63 |
| Number of Members | 63 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 3 |
| Number of Load Combinations | 8 |
| Number of Result Combinations | 0 |
| Total Weight | 6.809 tons |
| Dimensions (Metric) | 26.000 x 20.230 x 4.497 m |
| Dimensions (Imperial) | 85.3 x 66.37 x 14.75 feet |
