Rebar Layout Visualization in Cross-Section and 3D View
Cross-section and 3D view display rebar layout for individual elements.
The depiction shows the configuration of longitudinal and shear reinforcement in structural components. The reinforcement layout is displayed both in cross-section and a 3D visualization, allowing for detailed inspection of the arrangement. The visual includes various reinforcement options with specific coordinates related to the cross-section's centroid.
