Defining Mode Shape from Modal Analysis
Defining a mode shape from modal analysis
The image shows a buckling mode resulting from a modal analysis to determine cases of imperfection. A specific mode shape is selected to allow for the analysis of structural instabilities. Modal analysis helps engineers identify critical points in the structure and plan appropriate measures to secure the structure. The process displayed is crucial for the integral design of safe and stable building structures.
