KB 1999 | Two-Span Continuous Beam with Different Span Widths

Structural system with two-span beam, width of Span 1: 5 m, Span 2: 4 m.
The image shows a structural system consisting of a two-span beam. The widths of the spans are different, with Span 1 of 5.000 m and Span 2 of 4.000 m. Both spans are part of the entire beam system that transfers the loads over the given distance. This structure is often used in engineering projects to distribute loads efficiently.
