Deformation Diagram of Steel Structure in RFEM
Deformation analysis of a steel structure subjected to a load, created using the RFEM software.
The image shows the deformation of a steel structure subjected to loads, simulated in the RFEM software. Structural analysis and load distribution are visualized. The focus is on the plastic deformation and stability analysis of the material used. This analysis is used to check the load-bearing capacity and optimize the design. Photo by © CRAFT Engineering Studio.
3D Model
No Download Possible
Customer Project / View Only
More About 3D Model
Specifications
| Number of Nodes | 425 |
| Number of Lines | 903 |
| Number of Members | 782 |
| Number of Surfaces | 323 |
| Number of Solids | 0 |
| Number of Load Cases | 8 |
| Number of Load Combinations | 28 |
| Number of Result Combinations | 0 |
| Total Weight | 10.702 t |
| Dimensions (Metric) | 14.772 x 9.293 x 8.018 m |
| Dimensions (Imperial) | 48.46 x 30.49 x 26.31 feet |
