Concrete River Channel
Concrete river channel. Display of flow simulations and mechanical details in the design process.
Concrete river channel designed for the study of fluid mechanics. Engineering details of the construction are visible. The channel is used for the targeted control of water flow. Flow simulations support optimal design. Mechanical structures within the channel improve efficiency.
Used in
3D Model
Specifications
| Number of Nodes | 33 |
| Number of Lines | 56 |
| Number of Members | 0 |
| Number of Surfaces | 22 |
| Number of Solids | 0 |
| Number of Load Cases | 7 |
| Number of Load Combinations | 4 |
| Number of Result Combinations | 0 |
| Total Weight | 3881.739 t |
| Dimensions (Metric) | 54.598 x 6.850 x 55.000 m |
| Dimensions (Imperial) | 179.13 x 22.47 x 180.45 feet |
