Steel Design Detail: Column with Haunched Beam

RFEM 6 model with a refined steel construction detail shows a haunched beam cross-section on a column.

The image shows a detail from steel construction, depicting a haunched cross-section of a beam connected to a column. The model was created with the RFEM 6 software, which is used for the analysis and design of structural models. Haunched cross-sections are often used to efficiently distribute loads.
