Continuous Beam with Hinges and Overhanging Ends
A continuous Gerber beam with a hinge configuration featuring a first bay without hinges, subsequent bays with one hinge each, and overhanging ends.
The image shows a continuous beam model designed as a Gerber beam, which incorporates hinges in its structure. The configuration starts with a bay that lacks a hinge, followed by sections where each features a hinge. The beam ends extend beyond the supports, known as overhanging ends.
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 8 |
| Number of Lines | 7 |
| Number of Members | 7 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 7 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.131 tons |
| Dimensions (Metric) | 7.000 x 0.000 x 0.000 m |
| Dimensions (Imperial) | 22.97 x 0 x 0 feet |
