Symmetric Rectangular Foundation
Diagram showing a symmetric rectangular foundation layout with dimensions and structural details.
The image depicts a symmetric rectangular foundation with detailed measurements and structural annotations. It presents a technical layout useful for understanding symmetric balance in foundation design.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 8 |
| Number of Lines | 12 |
| Number of Members | 0 |
| Number of Surfaces | 6 |
| Number of Solids | 1 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 5.000 tons |
| Dimensions (Metric) | 2.000 x 0.500 x 2.000 m |
| Dimensions (Imperial) | 6.56 x 1.64 x 6.56 feet |
