Scaffolding With Parallelogram Shape And Load Application
Scaffolding falsework modeled in a parallelogram shape showing the applied loads.
The image depicts scaffolding falsework arranged in a parallelogram shape. Loads are applied to the structure, demonstrating load-bearing capabilities. The composition and graphic representation provide insight into the stability and efficiency of such support systems in construction.
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 114 |
| Number of Lines | 127 |
| Number of Members | 123 |
| Number of Surfaces | 1 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 1.434 tons |
| Dimensions (Metric) | 6.072 x 3.000 x 4.000 m |
| Dimensions (Imperial) | 19.92 x 9.84 x 13.12 feet |
