Layer Manager
The user interface of the Layer Manager shows a hierarchical structure into the categories of all layers and defined layer groups. The table lists 16 specific layers, including Standard, HG columns, HG stairs, NG beams, and construction lines. Each layer has control elements for visibility (lamp icon) and lock status (lock icon). Individual colors and line types such as continuous or dashed are assigned to the layers. The Assigned objects column shows which elements are assigned to the respective layers.
