Single-Span Beam with Tendons in Construction Stages
Simulation of a single-span beam with and without prestressing tendons using construction stages for structural analysis.
The model displays a single-span beam analyzed in two configurations: one as a classical simply supported beam and the other with added prestressing tendons to evaluate their impact.
Utilisé dans
Modèle 3D
Spécifications
| Nombre de nœuds | 11 |
| Nombre de lignes | 5 |
| Nombre de barres | 5 |
| Nombre de surfaces | 0 |
| Nombre de solides | 0 |
| Nombre de cas de charge | 8 |
| Nombre de combinaisons de charges | 19 |
| Nombre de combinaisons de résultats | 0 |
| Poids total | 20,167 t |
| Dimensions (métriques) | 22,500 x 0,430 x 0,240 m |
| Dimensions (impériales) | 73.82 x 1.41 x 0.79 feet |
