Steel Column with Reinforced Concrete Footing
Steel column anchored by a reinforced concrete footing in a construction detail.
A steel column is shown mounted on a reinforced concrete footing. The footing secures the column as part of a typical foundation system. The depicted assembly reflects standard engineering principles for transferring loads to the ground.
用于
3D 模型
详细说明
| 节点数目： | 2 |
| 线的数目 | 1 |
| 杆件数目： | 1 |
| 面的数目： | 0 |
| 实体数目 | 0 |
| 荷载工况数目 | 3 |
| 荷载组合数目 | 5 |
| 结果组合数目 | 2 |
| 总重量 | 0,076 t |
| 翘曲区域尺寸 | 0.000 x 2.500 x 0.000 m |
