Hall with Membrane Roof
Number of Nodes | 129 |
Number of Lines | 199 |
Number of Members | 195 |
Number of Surfaces | 26 |
Number of Solids | 0 |
Number of Load Cases | 3 |
Number of Load Combinations | 0 |
Number of Result Combinations | 0 |
Total Weight | 136.247 tons |
Dimensions | 57.41 x 26.17 x 98.43 feet |
