Steel column with Structure Stability to demonstrate Euler buckling capacity.
Steel Column | Euler Buckling
Number of Nodes | 2 |
Number of Lines | 1 |
Number of Members | 1 |
Number of Surfaces | 0 |
Number of Solids | 0 |
Number of Load Cases | 1 |
Number of Load Combinations | 2 |
Number of Result Combinations | 0 |
Total Weight | 0.191 tons |
Dimensions | 0 x 12 x 0 feet |
