Selection of Members in 2D Structural Systems with Plate Action
Display of the selection options in a 2D structural system with plate action, where failing members are deactivated.
The image shows the selection of members that fail in a 2D structural system defined with plate action. In this structural system, failures are not activated by default, as they are not required. Therefore, there is no option to select these member types. The graphical surface clearly illustrates these structural system settings.
