Concrete Helical Staircase with Midlanding in Cylinder Shape
Single-flight cylindrical staircase made of concrete with midlanding; designed with a helical, right-hand orientation.
The image displays a single-flight cylindrical right-hand staircase constructed from concrete, featuring a midlanding. The helical design is incorporated within a cylindrical geometry, exemplifying modern and dynamic architectural design in structural engineering.
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 88 |
| Number of Lines | 96 |
| Number of Members | 0 |
| Number of Surfaces | 9 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 19.907 tons |
| Dimensions (Metric) | 10.000 x 4.100 x 5.000 m |
| Dimensions (Imperial) | 32.81 x 13.45 x 16.4 feet |
