Concrete single-flight cylindrical right-hand staircase with midlanding.
STC019 | Cylindrical Staircase with Midlanding
| Block parameters editable dynamically | |
| Number of Nodes | 88 |
| Number of Lines | 96 |
| Number of Members | 0 |
| Number of Surfaces | 9 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 19.907 tons |
| Dimensions | 32.81 x 13.45 x 16.4 feet |
