Animation of Bridge Construction with Construction Stage Analysis Add-on
Animation of Bridge Construction - CSA
3D Model
Specifications
| Number of Nodes | 98 |
| Number of Lines | 121 |
| Number of Members | 108 |
| Number of Surfaces | 8 |
| Number of Solids | 0 |
| Number of Load Cases | 8 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 1495.991 tons |
| Dimensions (Metric) | 60.000 x 15.000 x 15.000 m |
| Dimensions (Imperial) | 196.85 x 49.21 x 49.21 feet |
2024-03-09
026251
Reinforced Concrete Structure and Application of Construction Stage Analysis
Reinforced Concrete Structure and Application of CSA Add-on
3D Model
Specifications
| Number of Nodes | 125 |
| Number of Lines | 144 |
| Number of Members | 33 |
| Number of Surfaces | 23 |
| Number of Solids | 0 |
| Number of Load Cases | 4 |
| Number of Load Combinations | 14 |
| Number of Result Combinations | 2 |
| Total Weight | 901.247 tons |
| Dimensions (Metric) | 33.528 x 14.630 x 12.192 m |
| Dimensions (Imperial) | 110 x 48 x 40 feet |
2021-12-02
026247
Deformation Results and Visualization Using Construction Stage Analysis Add-on
Deformation Results Using CSA Add-on
3D Model
Specifications
| Number of Nodes | 75 |
| Number of Lines | 134 |
| Number of Members | 10 |
| Number of Surfaces | 60 |
| Number of Solids | 0 |
| Number of Load Cases | 3 |
| Number of Load Combinations | 11 |
| Number of Result Combinations | 0 |
| Total Weight | 723.000 tons |
| Dimensions (Metric) | 12.000 x 30.000 x 4.000 m |
| Dimensions (Imperial) | 39.37 x 98.43 x 13.12 feet |
