Model 004297 | Multistory Frame Made of Steel with Bracing Diagonals
3D Model
Specifications
| Number of Nodes | 8 |
| Number of Lines | 12 |
| Number of Members | 12 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 4 |
| Number of Result Combinations | 0 |
| Total Weight | 4.731 tons |
| Dimensions (Metric) | 5.000 x 15.000 x 0.000 m |
| Dimensions (Imperial) | 16.4 x 49.21 x 0 feet |
2024-05-30
041978
Multistory Frame Made of Steel with Bracing Diagonals | Connection Detail
Multistory Frame Made of Steel with Bracing Diagonals
3D Model
Specifications
| Number of Nodes | 8 |
| Number of Lines | 12 |
| Number of Members | 12 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 4 |
| Number of Result Combinations | 0 |
| Total Weight | 4.731 tons |
| Dimensions (Metric) | 5.000 x 15.000 x 0.000 m |
| Dimensions (Imperial) | 16.4 x 49.21 x 0 feet |
