INAIL Headquarters in Ancona| © ATI Project
INAIL Ancona Headquarters renovation with sustainable design and modern hydrotherapy spaces.
The image details the conversion of a former IPSIA high school into the new INAIL headquarters in Ancona, Italy. The building spans 6,600 sqm over four above-ground levels and features large volumes accented by stone cladding and rhythmic openings. Regular voids, a prominent transparent entrance, and carefully chosen colors highlight its public function. The design employs prefabricated prestressed reinforced concrete and BIM methodology to ensure efficiency, with dedicated spaces for hydrotherapy, health, and rehabilitation alongside offices for regional authorities.
Used in
3D Model
Specifications
| Number of Nodes | 571 |
| Number of Lines | 976 |
| Number of Members | 613 |
| Number of Surfaces | 236 |
| Number of Solids | 0 |
| Number of Load Cases | 15 |
| Number of Load Combinations | 127 |
| Number of Result Combinations | 5 |
| Total Weight | 1953.721 tons |
| Dimensions (Metric) | 71,050 x 16,176 x 23,935 m |
| Dimensions (Imperial) | 233.1 x 53.07 x 78.53 feet |
