Steel Bolted Connection with Internal Forces Exported

Model 005791 | RFEM model showing a steel bolted connection with stiffeners and an I-beam, including exported internal forces from a roofing structure.
The image displays an RFEM model of a steel bolted connection in structural engineering. The model includes an I-beam reinforced with stiffeners. This configuration demonstrates the transfer of internal forces from a roofing structure. The image emphasizes the practical application of a steel bolted connection.
