Timber-Concrete Composite Beam
Timber-concrete composite beam structure with concrete slab and timber beams in a structural model.
The image shows a timber-concrete composite structure that combines a concrete slab with timber beams to increase load-bearing capacity. This structure efficiently utilizes the strengths of both materials. The timber beams are arranged beneath the concrete slab. Such structures are ideal for structural projects that require both strength and flexibility.
Used in
3D Model
Specifications
| Number of Nodes | 12 |
| Number of Lines | 11 |
| Number of Members | 2 |
| Number of Surfaces | 2 |
| Number of Solids | 0 |
| Number of Load Cases | 2 |
| Number of Load Combinations | 9 |
| Number of Result Combinations | 0 |
| Total Weight | 9.761 t |
| Dimensions (Metric) | 12.000 x 0.200 x 2.000 m |
| Dimensions (Imperial) | 39.37 x 0.66 x 6.56 feet |
