Model 006388 | Warping Torsion in Cantilever – Division into Mt,pri and Mt,sec
Model 006388 | Warping torsion in cantilever – breakdown into Mt,pri and Mt,sec
Top view of the model for Warping Torsion. A cantilever with an I-section is fixed at one end and restrained against camber; the other end is free. In the model, the beam is subjected to a torsional moment of 10 kNm at the free end.
3D Model
Specifications
| Number of Nodes | 2 |
| Number of Lines | 1 |
| Number of Members | 1 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 3 |
| Number of Load Combinations | 1 |
| Number of Result Combinations | 0 |
| Total Weight | 0.332 t |
| Dimensions (Metric) | 5.000 x 0.000 x 0.000 m |
| Dimensions (Imperial) | 16.4 x 0 x 0 feet |
