Cross-Section Modeling Based on DXF Files

[Dlubal Software]

In the software SHAPE-THIN, you can import cross-section geometries that are available as outline or centroid layouts in DXF format and use them as a basis for modeling.

The following options are available to create the cross-section:
- Creating elements automatically and continue editing
- Use DXF template lines as centerlines of elements with defined thickness
- Create DXF template for further editing
