Reinforced Concrete Hall with Steel Purlins
Number of Nodes | 49 |
Number of Lines | 78 |
Number of Members | 78 |
Number of Load Cases | 4 |
Total Weight | 82.962 tons |
Dimensions | 49.61 x 66.02 x 30.14 feet |
Program Version | 5.23.01 |
