Download the model of a truss connection here and open it with the structural FEA software RFEM 6.

This model is used in the webinar 'Analysis of Steel Joints Using FE Model in RFEM 6 ' on Aug 10, 2022 (Arabic).


(0)
0 颗星,最多 5 颗星
5 星 0
4 星 0
3 星 0
2 星 0
1 星 0

有连接的钢桁架

节点数目: 18
线的数目 33
杆件数目: 33
面的数目: 0
实体数目 0
荷载工况数目 2
荷载组合数目 2
结果组合数目 0
总重量 3,351 t
翘曲区域尺寸 20.000 x 2.500 x 0.000 m

您可以下载该结构分析模型来进行专业练习,或者用于您的工程项目。 但是我们不保证模型的准确性或完整性,也不承担任何责任。
