A two-layered, open-ended thick-walled vessel is loaded by inner and outer pressure, therefore, there is no axial stress. While neglecting self‑weight, the radial deflection of the inner and outer radius and the pressure (radial stress) in the middle radius is determined.
Verification Example 000065 | 1
| Number of Nodes | 9 |
| Number of Lines | 7 |
| Number of Members | 0 |
| Number of Surfaces | 2 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Dimensions | 0.98 x 0 x 0.98 feet |
