German Standards (DIN)

DIN Standards

German DIN Standards

The following DIN standards are implemented in the programs by Dlubal Software:

  • DIN 1055‑100
    (Load cases / load combinations)
  • DIN 1045‑1
    (Concrete structures)
  • DIN 18800
    (Steel structures)
  • DIN 1052
    (Timber structures)
  • DIN 4149
    (Earthquake resistance)

DIN standards are no longer valid but they may be required for the design verification of existing buildings. In Germany, Eurocodes are used for new buildings.

Newsletter

Receive regular information about news, useful tips, scheduled events, special offers, and vouchers at least once a month.

Structural Design According to DIN Standards

In Germany, structures are designed according to Eurocodes and the relevant German National Annexes (DIN EN). However, the verification of designed and built structures may require to use the DIN standards that are not valid anymore. Therefore, these DIN standards are supported by Dlubal Software products.

Implemented DIN Standards

  1. Basic combination

    Automatic Creation of Combinations in RFEM and RSTAB

    In RFEM and RSTAB, the load and result combinations are automatically created according to the following German standards:

    • DIN 1055-100
    • DIN 1055-100 + DIN 1052
    • DIN 1052 (simplified)
    • DIN 18800
  2. Reinforcement in 3D rendering

    Design of Reinforced Concrete Members and Surfaces According to DIN 1045-1

    DIN 1045-1 for RFEM/RSTAB extends various concrete modules with the following German standards:

    • DIN 1045-1:2008-08
    • DIN 1045-1:1988-07
  3. Design results of RF-/STEEL in 3D rendering

    Steel Design According to DIN 18800

    RF-/STEEL performs stress analysis of members and surfaces according to the German standard DIN 18800.

  4. Timber design according to DIN 1052

    Timber Design According to DIN 1052

    RF-/TIMBER Pro performs all typical designs of the ultimate limit state, serviceability limit state, stability analysis, and fire resistance design of timber structures according to the German standard DIN 1052:2008‑12.

  5. Natural vibrations of housing complex (C) www.rubner.com

    Earthquake Resistance Design According to DIN 4149-1

    RF-/DYNAM Pro - Natural Vibrations determines natural frequencies and mode shapes.

    RF-/DYNAM Pro - Equivalent Loads generates equivalent lateral loads for earthquakes using multimodal response spectrum analysis according to the German standards DIN 4149‑1:1981‑04 and DIN 4149‑1:2005‑04.

Contact us

Contact to Dlubal

Do you have any questions about our products? Do you need any information about the standards implemented in Dlubal Software products?
Contact our technical support or find various suggested solutions and useful tips on our FAQ page.

+49 9673 9203 0

info@dlubal.com

Customer Projects

Customer Projects designed by Dlubal Software products

Interesting customer projects designed with the structural analysis programs by Dlubal Software.

RFEM Main Program
RFEM 5.xx

Main Program

Structural engineering software for finite element analysis (FEA) of planar and spatial structural systems consisting of plates, walls, shells, members (beams), solids and contact elements

RSTAB Main Program
RSTAB 8.xx

Main Program

The structural engineering software for design of frame, beam and truss structures, performing linear and nonlinear calculations of internal forces, deformations, and support reactions

RFEM Concrete Structures
RF-CONCRETE 5.xx

Add-on Module

Design of reinforced concrete members and surfaces (plates, walls, planar structures, shells)

RFEM Concrete Structures
RF-CONCRETE Columns 5.xx

Add-on Module

Reinforced concrete design according to the model column method (method based on nominal curvature)

RFEM Concrete Structures
DIN 1045-1 for RFEM 5.xx

Module Extension for RFEM

Extension of the modules for reinforced concrete design by the DIN 1045-1 design

RFEM Concrete Structures
RF-FOUNDATION Pro 5.xx

Add-on Module

Design of single, bucket and block foundations

RFEM Steel and Aluminium Structures
RF-STEEL 5.xx

Add-on Module

Stress analysis of steel surfaces and members

RFEM Timber Structures
RF-TIMBER Pro 5.xx

Add-on Module

Timber design according to Eurocode 5, SIA 265 and/or DIN 1052

RFEM Dynamic Analysis
RF-DYNAM Pro - Natural Vibrations  5.xx

Add-on Module

Dynamic analysis of natural frequencies and mode shapes of member, surface, and solid models

RFEM Dynamic Analysis
RF-DYNAM Pro - Equivalent Loads 5.xx

Add-on Module

Seismic and static load analysis using the multi-modal response spectrum analysis

RSTAB Concrete Structures
CONCRETE 8.xx

Add-on Module

Linear and nonlinear analysis of reinforced concrete members with reinforcement concept

RSTAB Concrete Structures
CONCRETE Columns 8.xx

Add-on Module

Reinforced concrete design according to the model column method (method based on nominal curvature)

RSTAB Concrete Structures
DIN 1045-1 for RSTAB 8.xx

Module Extension for RSTAB

Extension of the modules for reinforced concrete design by the DIN 1045-1 design

RSTAB Concrete Structures
FOUNDATION Pro 8.xx

Add-on Module

Design of single, bucket and block foundations

RSTAB Steel and Aluminium Structures
STEEL 8.xx

Add-on Module

Stress analysis of steel members

RSTAB Timber Structures
TIMBER Pro 8.xx

Add-on Module

Timber design according to Eurocode 5, SIA 265 and/or DIN 1052

RSTAB Dynamic Analysis
DYNAM Pro - Natural Vibrations 8.xx

Add-on Module

Dynamic analysis of natural frequencies and mode shapes of member models

RSTAB Dynamic Analysis
DYNAM Pro - Equivalent Loads 8.xx

Add-on Module

Seismic and static load analysis using the multi-modal response spectrum analysis
