Find here a variety of wind simulations models to download, which you can use for training purposes or for your projects.
Software for Wind Simulation & Wind Load Generation on Structures
Structural FEM Analysis and Design
The structural analysis software RFEM 6 is the basis of a modular program family. The RFEM main program is used to define structures, materials, and loads for planar and spatial structural systems consisting of plates, walls, shells, and members. The program also allows you to create combined structures as well as model solid and contact elements.
Structural Frame & Truss Analysis Software
The structural frame and truss analysis software RSTAB 9 has similar functions as the FEA software RFEM. Due to the special attention to beam, frame, or truss structures, it is very easy to use and for many years, it has been the best choice for structural analysis and design of pure structural member models.
CFD Simulation of Wind Flow
The RWIND 2 stand-alone program is recommended for complex structures. Utilize this program to simulate wind flow (digital wind tunnel) around buildings or any other objects and generating wind loads, that is the forces acting on these objects based on CFD.
Import the generated wind loads acting on these objects to the structural analysis and design software RFEM or RSTAB.
Interfaces for Data Exchange
The structural analysis software provided by Dlubal Software can be integrated seamlessly into the Building Information Modeling (BIM) process. The large number of interfaces ensures the data exchange of digital building models with RFEM or RSTAB.
The web service (programmable interface) can be used to read or write data from/to RFEM and RSTAB.
